QG、JG、FG Air Stream Dryer

The QG JG Series Air Stream is a high-capacity drying system. It adopts instant drying technology. By harnessing hot air to suspend wet materials, it intensifies heat and mass transfer, enabling complete removal of free moisture (e.g., reduces starch moisture from ≤40% to 13.5%). No material degradation, higher output than conventional dryers. Rapid ROI through energy-efficient bulk processing.

Model:
QG、JG、FG

Quantity:
Availability:





Inquire

Product Features

Applications

Parameters

Product Features

The FG Series dryer operates through a two-stage drying process designed for efficiency and versatility:

Primary Drying (Positive Pressure Stage)

Raw material is pre-dried using a blended heat source composed of recycled exhaust air from the secondary drying stage and supplemental hot air. The high-temperature and low-humidity exhaust air is exhaust after primary drying. The semi-dried material go for secondary drying with fresh hot air under negative pressure. The final dried product is discharged for precision weighing and packaging.

Applications

Suitable used in drying powder material of Pharmaceuticals, Chemicals, Food, Building Materials , Plastics industry.

▸ Food: Starch, fish meal, salt, brewer's grains, gluten

▸ Industrial: Plastic resins, mineral/coal powders

▸ Chemicals: Chlorosugar acid, A.S.C benzoic acid, 2.3-acid

▸ Polymers: PVC, polypropylene

▸ Salts: Sodium sulfate, sodium metabisulfite

Pharmaceutical

Food Manufacturing

Plastics Resin

Chemical Industry

Parameters

Model	Evaporated moisture kg/h	Installed power kw	Area covered m²	Altitude m
Model	(Calculated by surface moisture)	Installed power kw	Area covered m²	Altitude m
JG 50	50	10	20	9
JG 100	100	20	32	11
JG 200*	200	31	40	11
JG 250	250	32	64	13
JG 500*	500	54	96	13
JG 1000*	1000	135	120	15
JG 1500*	1500	175	200	16

Model	Evaporated moisture (kg/h)	Installed power kw	Area covered m²	Thermal efficiency (%)
FG0.25	113	11	3.5x2.5	>60
FG0.5	225	18.5	7x5	>60
FG0.9	450	30	7x6.5	>60
FG1.5	675	50	8x7	>60
FG2.0	900	75	11x7	>60
FG2.5	1125	90	12x8	>60
FG3.0	1150	110	14x10	>60
FG3.5	1491	110	14x10	>60
