Working Principle
1. Efficient Heat Transfer System
○ Specially designed wedge-shaped hollow paddles provide high heat transfer efficiency with self-cleaning surfaces.
○ Heat transfer medium (steam/thermal oil/hot water from -40°C to 320°C) circulates through:
■ Jacketed vessel walls
■ Hollow agitator shafts (custom internal structures for different media)
■ Densely arranged wedge-shaped paddle interiors
○ 100% indirect conduction heating (no heat loss to carrier gas)
2. Unique Ω-Shaped Design
○ Horizontal vessel with 2-4 hollow shafts
○ Sealed end covers prevent material leakage
Low Energy Consumption
● Only 1.2kg steam required per kg water evaporated
● Minimal heat loss (limited to insulation losses)
Compact & Cost-Effective
● High surface-area-to-volume ratio reduces processing time and footprint
Broad Material Compatibility
● Handles both heat-sensitive and high-temperature materials
● Compatible media: steam, thermal oil, hot/cooling water
Environmentally Friendly
● Minimal dust emission (closed-loop operation available)
● Low solvent evaporation
Low Maintenance
● Wear-resistant design with minimal moving parts
Process Stability
● Wedge paddles' compression-expansion action ensures uniform:
○ Temperature distribution
○ Moisture content
○ Material mixing
