Featuring rapid drying speed, high evaporation intensity, and superior product quality, it can also process paste-like materials (e.g., filter cake residues) after granulation or extrusion.
1. Material Loading: Feed is evenly distributed onto a 12-60 mesh stainless steel conveyor belt, driven through drying chambers.
2. Modular Design: Consists of multiple independent units with dedicated hot air circulation. Partial exhaust is removed by dehumidification fans.
3. Airflow Options:
○ Cross-flow configuration (upward/downward) for optimal heat-mass transfer
○ Adjustable baffle system ensures uniform air distribution
4. Process Control:
○ Belt speed adjustable based on material moisture/temperature
○ Continuous discharge into collection vessels
|
Product Features
✔ Precision Control: Adjustable air volume, temperature (50-300°C), residence time, and feed rate
✔ Flexible Configuration: Optional belt cleaning system and post-drying cooling modules
✔ Energy Efficiency: 70-80% air recirculation rate
✔ Uniform Drying: Patented airflow distribution technology guarantees consistent product quality
✔ Multi-Source Heating: Compatible with steam, thermal oil, electric, or coal/oil-fired hot air systems
|
Applications
● Food: Dehydrated vegetables, coconut flakes, monosodium glutamate
● Industrial: Organic pigments, synthetic rubber, acrylic fibers
● Pharmaceuticals: Herbal extracts, granules
● Others: Plastic products, electronic component aging/curing
Pharmaceutical
Food Manufacturing
Feed
Chemical Industry
|
Parameters
| Model | DW-1.2-8 | DW-1.2-10 | DW-1.6-8 | DW-1.6-10 | DW-2-8 | DW-2-10 | DW-2-20 | |
| Modules No. | 4 | 5 | 4 | 5 | 4 | 5 | 10 | |
| Belt Width (m) | 1.2 | 1.6 | 2 | |||||
| Drying Section Length (m) | 8 | 10 | 8 | 10 | 8 | 10 | 20 | |
| Material Layer Thickness (mm) | 10-80 | |||||||
| Operating Temperature (°C) | 50-140 | |||||||
| Steam Pressure (MPa) | 0.2-0.8 | |||||||
| Steam Consumption (kg/h) | 120-300 | 150-375 | 150-400 | 180-500 | 180-500 | 225-600 | 450-1200 | |
| Drying Time (h) | 0.2-1.2 | 1.25-1.5 | 0.2-1.2 | 0.25-1.5 | 0.2-1.2 | 0.25-1.5 | 0.5-3 | |
| Drying Capacity (kg.water /h) | 60-160 | 80-200 | 85-220 | 100-260 | 100-260 | 120-300 | 240-600 | |
| Total Power (kw) | 11.4 | 13.6 | 14.6 | 18.7 | 19.7 | 24.5 | 51 | |
| L (m) | 9.56 | 11.56 | 9.56 | 11.56 | 9.56 | 11.56 | 21.56 | |
| Overall Dimensions | W (m) | 1.49 | 1.49 | 1.9 | 1.9 | 2.32 | 2.32 | 2.32 |
| H (m) | 2.3 | 2.3 | 2.4 | 2.4 | 2.5 | 2.5 | 2.5 | |
| Weight (kg) | 4500 | 5600 | 5300 | 6400 | 6200 | 7500 | 14000 | |
| Model | DW3-1.2-8 | DW3-1.2-10 | DW3-1.6-8 | DW3-1.6-10 | DW3-2-8 | DW3-2-10 |
| Modules No. | 4×3 | 5×3 | 4×3 | 5×3 | 4×3 | 5×3 |
| Belt Width (m) | 1.2 | 1.6 | 2 | |||
| Drying Section Length (m) | 8×3 | 10×3 | 8×3 | 10×3 | 8×3 | 10×3 |
| Material Layer Thickness (mm) | 10-80 | |||||
| Operating Temperature (°C) | 50-140 | |||||
| Steam Pressure (MPa) | 0.2-0.8 | |||||
| Steam Consumption (kg/h) | 360-600 | 420-720 | 450-840 | 480-960 | 480-960 | 630-1350 |
| Drying Time (h) | 816 | 1020 | 1056 | 1320 | 1344 | 1680 |
| Drying Capacity (kg.water /h) | 150-450 | 220-550 | 240-600 | 280-750 | 280-750 | 350-900 |
| No. of Fans (Unit) | 14 | 17 | 14 | 17 | 14 | 17 |
| Total Power of interior (kw) | 30.8 | 37.4 | 42 | 51 | 56 | 68 |
| Total Power (kw) | 35.3 | 41.9 | 46.5 | 55.5 | 60.5 | 72.5 |
| Overall Dimensions (L×W×H) | 9.77×2.2×4.5 | 11.77×2.2×4.5 | 9.77×2.6×4.7 | 11.77×2.6×4.7 | 9.77×3.06×4.9 | 11.77×3.06×4.9 |
| Weight (kg) | 4800×3 | 5780×3 | 5400×3 | 6550×3 | 6350×3 | 7800×3 |
